Specification
| BAR | FSA KFX SIC Carbon 65x780mm |
|---|---|
| BRAKE | Trickstuff Piccola C22 2-Piston |
| BRAKE DISC (FRONT) | Trickstuff Dächle UL 6bolt 160 |
| BRAKE DISC (REAR) | Trickstuff Dächle UL 6bolt 160 |
| CHAIN | SRAM XX Eagle SL T-Type 12s |
| CRANKSET | SRAM XX SL T-Type Carbon DUB 34T PM |
| DERAILLEUR (REAR) | SRAM XX SL Eagle Transmission 12speed |
| FORK | RockShox SID SL Ultimate 29" 110 15x110 |
| FRAME | SCARP 29" Premium Carbon 110 UDH/M4920 |
| GRIP | ESI Chunky silicone |
| HEADSET | FSA ACR drop/in 1.5" internal |
| PERMISSIBLE TOTAL WEIGHT | 110KG |
| SADDLE | Selle Italia SLR Boost flow Carbon Rails |
| SEAT POST | RockShox Reverb AXS 30.9 T100 |
| SHIFT LEVER | SRAM POD Rocker AXS Controller |
| SHOCK | RockShox SID Luxe Ultimate|FlightAttendant 210x50 |
| SPROCKET | SRAM XX SL T-Type XS-1299 / 10-52 |
| TYRE (FRONT) | Maxxis Rekon Race MaxxSpeed/EXO/TR 61-622 |
| TYRE (REAR) | Maxxis Aspen MaxxSpeed/EXO/TR 61-622 |
| WEIGHT | 10.6KG |
| WHEEL (FRONT) | DT XRC1200 Spline 29 Carbon 6B 110/15TA|622x30TSS TLR |
| WHEEL (REAR) | DT XRC1200 Spline 29 Carbon 6B 148/12TA|622x30TSS XD TLR |
SCARP EXONIC
JOIN THE EVOLUTION
The racing DNA of the Scarp has always been a guarantee for highest quality and maximum performance. With great pride, we present the third evolution of our flagship in the cross- and down country sector
The EVO III frame is used across the entire range and marks the beginning of a new Scarp era
All models are the result of years of experience from KTM bicycle engineers, combined with feedback directly from the toughest race tracks in the world. The demands of the best racers, regarding geometry and handling, have thus been precisely transferred into production-bikes
For the final test, the Scarp Evo III frame had to prove itself at the Cape Epic in South Africa and at the Mountainbike World Cup in Brazil. The praises from the athletes confirmed the creation of a masterpiece. Particularly convincing are the many technical details reflecting perfection down to the last detail
The new Scarp frame is available in both carbon and aluminium
The suspension travel varies from 100 to 140mm
From entry-level full- suspension bikes to high-end machines, there are no limits to your riding pleasure
Size Guide
| Frame Size | L |
|---|---|
| Height | 175 - 184cm / 5'9"- 6'0" |
| BB Drop | 42 |
| Standover Height | 807 |
| Reach | 469 |
| Stack | 607 |
| Wheelbase | 1189 |
| Head Angle | 67,0° |
| Seat Angle | 75° (70,7°) |
